DELTA X
The new Delta X is a new fully modular design flow wrapping machine that offers high speed long dwell single jaws up to 200ppm. Its heavy duty and reliable design allows the Delta X to be integrated in automatic packaging lines. This platform offers complete visibility and access due to open frame guards design and moreover, it’s available both in stainless steel and painted.
Additional information
- Machine Speed up to 200 cycles per minute. Production output depends on film sealability and product characteristics.
- Film Cut-Off Min 100mm - 4.0” / Max 1200mm - 47”. Depending on film and product characteristics.
- Wrapping Materials Shrink barrier films, laminated, co-extruded and all sealable films.
- Film Reel Max Weight Depending on film reel width, up to 75 kg - 165 lbs.
- Electronic Platform Industrial PC. Other electronic control platform on request i.e. Allen Bradley, Siemens, Elau-Schneider, B&R.
- Power Requirement From 220 to 480 V, 50/60 Hz, 7kVA.
- Compressed Air 6 bar, 200 l/min.
- Machine Weight 1600 Kg - 3530 lbs.
PRODUCT DIMENSIONS
- length up to 650mm - 25.6” standard. Up to 1000mm - 39.0” on request.
- width 150mm - 5.9” standard narrow version (jaws 190mm - 7.5”). 300mm - 11.8” standard large version (jaws 345mm - 13.6”). 420mm - 16.5” on request (jaws 450mm - 17.7”).
- height up to 110mm - 4.3” standard (centre-axle 180). Up to 150mm - 6.0” on request (centre-axle 225). Up to 60mm - 2.4” on request (centre-axle 140).
FILM REEL DIMENSIONS
- coreø 76.2mm - 3” standard. 152.4mm - 6” on request.
- outerø 350mm - 13.8” standard for reel web width up to 800-900mm.
- width 500mm / 650mm - 19.7” / 25.5” standard. 800mm / 900mm - 31.5” / 35.5” on request.
