SPE
Fully automatic strapping press with vertical strapping
The fully automatic and maintenance-friendly SPE strapping press is equipped with the CFH-1 strapping head. The combination of a press with strapping ensures rapid strapping with maximum clamping force. The drive system delivers an exactly reproducible press force, accurate package height, adjustable after-press interval and a defined interval pressure. The SPE ensures optimal securing of pallet loads in the corrugated cardboard, printing, paper and paper bag industries.- For PP and PET strap
- Optimal strapping results due to high and continuous tension
- Adjustable compression for packages of up to 3000 Kg
- Easily integrated into existing conveyor systems
- Simple and fast operation via Touch screen
- No compressed air required
Additional information
Technical features
- Press SPE 2200 kg.
- Strapping Vertical.
- Package dimensions 800 – 1600 (W), 400 – 2400 (H).
- Electrical cabinet with PLC S7/300 proface.
- Strap type PP, PET.
- Alimentation 400 V + 3F + N+ T – 50 HZ 24 V DC 5 kW ±
- Pressure plate speed 200 /sec.
Options
- Bigger arch for bigger packages for pallet height 2100 - 3000mm. For pallet width 2000 - 2500mm.
- Underfeed strap guide for products without pallets.
- Small dimensions lance W 50mm, H 20mm.
- Height moveable lance H 100mm.
