Legi-Air 4050 E
Legi-Air 4050 E is a robust and proven print & apply system that meets all the requirements of a modern labeling system far beyond what is demanded today. Thanks to its consistent modular design, the system can be individually adapted to the particular application:
Printing modules from all leading manufacturers can be used in the Legi-Air 4050 E. The wide range of labeling applicators available and very stable. They allow any labeling position and apply very precisely even in high-speed applications. The latest version of the Legi-Air 4050 E has proven technology as well as some new highly interesting technical features.
Additional information
| Technical data | Legi-Air 4050E |
|---|---|
| Power supply | 92 to 263 V AC / 50 ~ 60 Hz, 5 Ampere |
| Weight | from 75 kg (depending on version) |
| Compressed air supply | 6 bar (clean, dry, oil-free according to DIN ISO 8573-1) |
| Compressed air consumption | 0.1 to 3 l per dispensing cycle, depending on label size |
| Ambient temperature | 2 to 35 °C |
| Humidity rel | 15 to 95 %, non-condensing |
| Dimensions (HxWxD) | 584 x 765 x 709 mm |
| Printing unit | Flexible printing module technology, e.g. Datamax, Sato, Zebra, Avery, CAB |
| Approval | CE mark |
